Bike Key Features
Build Kit
Frameset
Frame
Rangefinder Aluminum
Color
Silver
Suspension Fork
SR Suntour XCM32 Boost, Coil, NLO, DS, 120 mm OR RST Alpha 110-15 Coil MLC, 120 mm
Rear Shock
N/A
Components
Headset
FSA Orbit NO.57B 1.5 ZS
Seatpost
Salsa Guide 30.9, 0 offset
Stem
Salsa Guide 31.8, 60 mm, 6d
Grips/Bar Tape
Salsa File Tread
Saddle
WTB Volt Medium, Steel, 142 x 265 mm
Handlebar
Salsa Salt Flat 31.8, 750 mm width XS–SM; Salsa Rustler 31.8, 800 mm width M–XL
Drivetrain
Front Derailleur
N/A
Rear Derailleur
Shimano Deore M5120 SGS
Cassette
Shimano Deore M4100 11–46t, 10-speed
Chain
Shimano HG54
Crankset
FSA Alpha Drive, 30t, FSA 124.5 mm bottom bracket
Shifter
Shimano Deore M4100 (10-speed)
Brake Calipers
Shimano MT200 OR Tektro M520 OR Promax DSK-925
Rotors
Shimano RT10 Center Lock rotors (160 mm)
Wheels
Front Wheel
Shimano MT400 Center Lock 15 x 110 mm TA hub, WTB ST i40 32h 27.5" rim
Rear Wheel
Shimano MT200 Center Lock 10 x 141 mm QR hub, WTB ST i40 32h 27.5" rim
Front Tire
Maxxis Rekon 27.5 x 2.8", EXO, Wire Bead (not tubeless compatible)
Rear Tire
Maxxis Rekon 27.5 x 2.8", EXO, Wire Bead (not tubeless compatible)
Weight
Complete Bike
33 lb (with tubes, no pedals) for Medium
Geometry
| Size | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| A. Effective Top Tube | 568.2 | 590.5 | 614.8 | 643.5 | 670.1 |
| B. Stand Over | 678.6 | 698.3 | 737.2 | 769.1 | 798.7 |
| C. Reach | 395.0 | 416.0 | 439.0 | 465.0 | 489.0 |
| D. Stack | 605.6 | 610.2 | 614.9 | 624.2 | 633.4 |
| E. Total Seat Tube Length | 355.0 | 381.0 | 431.0 | 470.0 | 508.0 |
| F. Headtube Length | 95.0 | 100.0 | 105.0 | 115.0 | 125.0 |
| G. Headtube Angle |
68.0
|
68.0
|
68.0
|
68.0
|
68.0
|
| H. Seat Tube Angle |
74.0
|
74.0
|
74.0
|
74.0
|
74.0
|
| I. BB Drop | 58.0 | 58.0 | 58.0 | 58.0 | 58.0 |
| K. Chainstay Length | 439.0 | 439.0 | 439.0 | 439.0 | 439.0 |
| L. Fork Length Axle to Crown | 510.0 | 510.0 | 510.0 | 510.0 | 510.0 |
| M. Fork Offset | 46.0 | 46.0 | 46.0 | 46.0 | 46.0 |
| N. Wheelbase | 1100.6 | 1123.4 | 1148.3 | 1178.0 | 1205.8 |
| Crank Arm Length | 170.0 | 170.0 | 175.0 | 175.0 | 175.0 |
| Handlebar Width | 750.0 | 750.0 | 800.0 | 800.0 | 800.0 |
| Recommended Rider Height | 157.0 - 168.0 | 160.0 - 175.0 | 173.0 - 183.0 | 180.0 - 191.0 | 188.0 |
| Stem Length | 60.0 | 60.0 | 60.0 | 60.0 | 60.0 |
Measurements based on:
- OE spec 120mm 29/27.5+ suspension fork at 25% sag
- 27.5 x 2.8" tire measuring 722mm in diameter
- Standover is measured from vertically from ground to the top of the toptube, 50mm forward of the BB. Add 8-12.5mm (0.3-0.5") for 29 x 2.4-2.6" wheels/tires
Frame Specs
- Design Wheel/Tire Sizes 27.5 x 2.8–3.0"
- Alternate Wheel/Tire Sizes 29 x 1.9–2.6"
- Suspension Fork Length (Travel) 100–130 mm
- Fork Offset 46 mm
- Rear Spacing 141 x 10 mm QR
- Headset - Upper ZS44
- Headset - Lower ZS56
- Seatpost 30.9 mm
- Dropper Post Compatible Yes (internal)
- Seatpost Clamp 35.0 mm
- Front Derailleur Clamp N/A
- Front Derailleur Type N/A
- Derailluer Hanger FS2361
- Bottom Bracket 73 mm BSA, threaded
- Crankset (Max Ring) Boost 148 52 mm chainline only (32t max)
- Accessory Mounts Rear Rack Mounts: Yes, Salsa Post-Lock seatpost collar required; Downtube Accessory Mounts: 1; Top Tube Mounts: Yes, compatible with Salsa EXP Series Top Tube bag.
- Bottle Mounts 2
- Front Fender Mounts No
- Rear Fender Mounts No
